BioMIG Devices





About Us

  •

      Embedded PC

      3“ screen 640x480 color TFT

      Numeric Keyboard with 4 functions keys (on screen)

      Encrypted connection to server

      Ethernet, USB + external power supply connectors

      Only Online operations supported (No local data storage and no offline functionality)

      Device has a unique ID + FV unique ID

      Optional ID: Scanner device for automatic scanning of ID number and photo

      All system messages in Turkish language

      Remote Access from SGK for firmware update and remote diagnostic

      Remotly activation and deactivation is possible

      Remote inventory of all devices in the field

      Hygienic housing for hospital environment

     Transaction log

    405MHz 32 bits ARM-9 CPU + FingerVeinModuleCPU

    64MB Nand Flash memory, 128MB RAM(DDR2 266MHZ)

    3.5 inches LCD WVGA touch screen

    Touch keypad

    Finger Vein Sensor Hitachi UBR

    1.3M CMOS Camera

    13.56MHz Mifare/DesFire REFID Reader

    50.000 image log capacity

    100.000 transaction log apacity

    Ethernet, WiFi, 4G connection

    8 hours live battery

    TCP/IP, Wiegand 26/34 (Output), USB (Host &Slave), SD card(4GB), 2x Relay output

    Voice & Sound indication support MP3/MP4

    Magnetic Protection Ethernet port:1.5KV, Serial Port:15KV,

    Surge Protection IO: Optical isolation 2.5KV Over-Voltage 70V(DC)

    Relay spec. Optical isolation 2.5KV(DC) Contact rating AC:120V@ 0.5A DC:30V@ 1A

    Operating Temp. 0 ~ 55

    Operating voltage DC 12V, 1A

    Approval CE/FCC

    Illumination> < 2300 Lux

    Verification Time Less Than 1 Second

    FAR/FRR 0.0001% /0.01%



Finger Vein Solutions
